Suggested Payload Limit: |
55 lb |
|
Locking Force @ 80 psi (5.5 bar): |
520 lb |
|
Static Moment Capacity (X & Y): |
500 lbf-in |
|
Static Moment Capacity (Z): |
310 lbf-in |
|
Positional Repeatability - (X, Y, & Z): |
0.0006 in |
|
Weight - when coupled: |
1.75 lb |
|
Maximum distance between Master & Tool plate before locking at 87 psi (6 bar): |
0.08 in |
|
Pneumatic Pass-through Ports (qty) Size: |
(8) 1/8 NPT; G 1/8 (BSPP) |
|
