9120-RF4A-M | M | RF4A Electrical Module Assembly with 4-Pin Minifast Male Connector and High Power Pin Block - Master side |
9120-RF4A-T | T | RF4A Electrical Module Assembly with 4-Pin Minifast Female Connector and High Power Pin Block - Tool side |
Description: |
RF4A Electrical Module Assembly with 4-Pin Minifast Connector and High Power Pin Block |
Weight: |
Master 0.55 lbs (0.25 kg) Tool 0.40 lbs (0.18 kg) |
Materials: |
- Aluminum housing
- Precious metal-plated heads on spring pins
- Precious-metal-plated contact pins
- Nitrile seal.
|
Elec. Rating: |
9 Amp/250VAC |
Operational Temperature Range: |
-20 ーF - 150 ーF (-28.9 ーC - 65.6 ーC) |
|
Custom Application QC Models |
|
*May be compatible with other QC models. Please consult an ATI Account Manager for more information.
|
|
|
Master
Side Cable Mount Connector Mates |
|
There are no connector mates associated with this panel mount connector.
|
|
|
|
|
|
Tool
Side Cable Mount Connector Mates |
|
There are no connector mates associated with this panel mount connector.
|
|
|
Cables
There are no Cables associated with this module.
|
|
9630-20-RF4A.pdf |
RF4A Module Drawing
|
|
None currently available. See your Account Representative for more information.
|
9120-RF4A-T |
RF4A Tool Electrical Module Assembly with 4-Pin Minifast Female Connector and High Power Pin Block
|
9120-RF4A-M |
RF4A Master Electrical Module Assembly with 4-Pin Minifast Male Connector and High Power Pin Block
|
|
|
