主页 > 产品中心 > 机器人工具快换装置（Tool Changer） > Manual Tool Changers

ATI Industrial Automation has developed a new series of Manual Tool Changers that provides a cost-effective solution for quickly changing tools by hand. They feature a unique design that combines high strength, excellent repeatability and a patent-pending screw-cam locking mechanism with multiple fail-safe features, which resists vibration and prevents loosening. The new Manual Tool Changers also feature quick-action locking for one-handed manual operation. These robust and compact Manual Tool Changers can handle payloads up to 80 pounds (36 kg) and pass pneumatics and electrical signals.

Product Highlights

Manual one-handed actuation.
High strength-to-weight ratio.
Very small package size.
Integrated air pass-through ports.
Screw-cam results in high locking force.
Additional mounting flats for adding ATI utility modules.


Bring tooling to Master	Push button for quick locking (tighten knob to secure)	Unscrew knob to unlock

Manual Tool Changer Models

Click here for the new Manual Tool Changer Flyer!
